滤筒除尘器的 原理介绍 HOW DOES IT WORK
含尘气体从风口进入灰斗后，一部分较粗尘粒和凝聚的尘团，由于惯性作用直接落下，起到预收尘的作用。进入灰斗的气流折转向上涌入箱体，当通过脉冲褶皱滤筒时，粉尘被阻留在滤筒的外表面。净化后的气体进入滤筒上部的清洁室汇集到出风管排出。除尘器的清灰由脉冲电磁阀及控制仪完成，合理的清灰确保滤筒的使用寿命。除尘器工作时，随着过滤的不断进行，滤筒外表的积尘逐渐增多，除尘器的阻力亦逐渐增加。当达到设定值时，清灰控制器发出清灰指令，将滤筒表面的粉尘下来，并落入灰斗，整个过程为过滤、脉冲清灰、出风。
From the inlet,the big dust and dust ball will fall into the hopper for sake of the inertia force ,that is called pre-filter.The air flow in the hopper then upflows into the filter room and the rest dust is filtered on the surface of the filter cartridges.The clean air goes into clear room and discharges from the outlet.Pulse solenoid valve and controller are the dust collector’s dust-cleaning.Setting proper pulse cycle will prolongs the service life of the filter cartridge.During working time,time after time of gilter,the dust on the surface of the cartridge gradually increases,so does the resistance of the dust collector.When the resistance reaches the setting limit,the controller then start the process of dust-cleaning.The dust on the surface of the filter cartridge will fall into the hopper,this whole process called filter,pulse dust-cleaning and outlet.
滤筒除尘器 性能特点：
除尘备件采用脉冲褶式滤筒，结构紧凑，节省占地空间；
Filter cartridges-compact structure and saving space
滤筒采用一体化设计，密封性能好，方便安装更换，缩短停车时间；
The filter cartridge is integrated designing,good sealaility,convenient installation change and shorten the time for suspension.
滤筒备件采用表面过滤，过滤效率高；
Surface filter,high filter efficiency
可以适用于多种工况，对粉尘浓度偏大的行业特别适用；
Suitable for many applications ,especially for high density of dust industry
清灰，不积灰；
Good dust –cleaning,no dust gathering
与滤袋除尘器相比，褶式除尘器的结构简单，过滤面积显著提高，可增大过滤面积2.5-3倍左右，过滤效率高；
Compared with bag filter,the cartridge dust collector has simple structure,2.5-3times of the filterareas of the filter areas of bag filter and high filter efficiency.
是替代传统袋式除尘器、电除尘器的佳方案；
Compared with other types dust collector,the cartridge dust collector can be widely used in different density of dust industries and is the best replacement of the bag filter and electric dust collector.
脉冲褶皱式滤筒除尘器与传统的布袋除尘器的性能对比
有效过滤面积提高了2-3倍
Increasing 2-3 times of the effective filter area
降低了压差，提高了处理风量
Lowering the pressure drop and improving the air flow
降低了气布比，有效的提高了过滤效率
Lowering the proportions of air and filter media and improving the filter efficiency
脉冲反吹系统工作效率提高，节省能耗
Improving the efficiency of the pulse-jet system and saving the energy
滤筒元件变短变少，有利于安装
The short height and less number of filter elements,good for installation
文氏管、龙骨免除，结构简单
Gratly improving the service life of the spare parts and decreading the times of machine halt.
大大提升了除尘备件的使用寿命降低设备的停机次数。
Greatl improving the service life of the spare parts and decreasing the times of machine halt.
滤筒除尘器应用范围 |APPLICATION
各种袋式除尘器、电除尘器的改造、水泥、冶金、发电、铝业、化工、燃料、石化、电子、精细化工、医药及粉尘浓度较大的行业。
Replacing bag filter and electric dust collector,high dust density industries including cemeng,metallurgy,electricity,aluminum,chemical,dyetuff,petrochemical,electronics,fine chemicals 。
